Взрывозащищенный пластиковый кабельный ввод M20 CEAG KU-Perfect-KV-PA/Ex | 50.620 PASWL/EX

Description

Dome nut: Polyamide PA6
Dust cap: Polyethylene PE­LD
Sealing ring/outer part: Polychloroprene­Nitrile rubber CR/NBR
Sealing ring/inner part: Evoprene TPE (from M20x1,5)
Gland body: Polyamide PA6
Connecting thread: metric, as per EN 60423

Equipment group: II
Category / Zone: 2G, 2D and 3G/ 1, 2, 21, 22
Type of protection: Ex e, increased safety
Ex tD A21 ­ Protection by enclosures
Cable installation: fixed
Temperature range (°C): -20°C / +70 (M12 und M16)
Further information on page 23
­                                        30°C / +70 (M20 bis M63)
Protection grade: 66
Test standard: EN 60079­0 / EN 60079­7
EN 61241­0 / EN 61241­1
EC­Type certificate: PTB 99 ATEX 3101 X (M12 und M16)
PTB 99 ATEX 3128 X (M20 bis M63)
IECEx certificate: IECEx PTB 05.0004x
