750mm Cant Arm, Universal | Наклонный рычаг 750 мм, универсальный | SA765 | Legrand SWIFTS

  • Finish: Hot dip galvanised
  • Height (mm): 130
  • Information: Two bolt fixing. Can be used with open face at the top or bottom
  • Length (mm): 750
  • Material: Steel
  • Max. evenly distributed load (kgf): 136
  • Max. point load at outer end (kgf): 68
  • Standards: BS 6946, BS EN ISO 1461
  • Weight (kg): 2.2
  • Width (mm): 40
Артикул: SA765 Категория:
ID товара: 42241

Контакты для связи:

E-mail: info@qareket-engineering.com
Телефон: +7 777 182 86 89

Описание

Cantilever arms In addition to the cantilever arms listed, there are many other specialist support brackets for use with cable ladder These are detailed in the relevant sections in this catalogue Cantilever arms, universal Two bolt fixing. Can be used with open face at the top or bottom
